Applications

Hard wall hose suitable for transfer of a wide range of aggressive chemicals, solvents, alcohols, petroleum products and oils.Suitable for acids and chemicals up to a concentration of 98%.

Construction

• Inner Tube: Transparent UHMWPE (Ultra-High Molecular Weight Polyethylene), smooth, conductive black UHMWPE helix stripe (R ＜ 10⁶ Ω), food grade.

• Reinforcement: Multiple plies of high-strength synthetic fabric, embedded steel wire helix and conductive copper wires.

• Cover: Gray EPDM rubber, smooth, conductive black helix stripe, abrasion resistant, ozone resistant, weather resistant, cloth finish (other colors available upon request).

Temperature Range

-40 °C ～ +100 °C

Standards & Approvals

FDA compliant

Specifications

| Code     | ID      | ID      | OD      | Bend Radius | Working Pressure | Working Pressure | Packing Length |

<td style="font-variant-numeric: normal; font-variant-east-asian: normal; font-variant-alternates: normal; font-kerning: auto; font-optical-sizing: auto; font-feature-settings: normal; font-variation-settings: normal; font-variant-position: normal; font-stretch: normal;

	inch	mm	mm	mm	psi	bar	m
UASD019	3/4"	19.05	30	130	240	16	100
UASD025	1"	25.4	36	150	240	16	100
UASD032	1‑1/4"	31.8	43	200	240	16	100
UASD038	1‑1/2"	38.1	49	225	240	16	100
UASD051	2"	50.8	62	275	240	16	100
UASD063	2‑1/2"	63.5	76	275	240	16	100
UASD076	3"	76.2	89	400	240	16	100
UASD102	4"	101.6	116	800	240	16	100
UASD127	5"	127	144	1300	240	16	100
