Construction: Type TSPO is manufactured from High purity platinum
cured Silicone with single stainless steel helix and polyester fiber
reinforcement. Temp. Range: -60 。C and 180 。C. (+260 。C on request)
Color: Transparent (Colored covers available)
Smooth inner and outer surface to resist material adhesion Suitable for pressure and vacuum. Suitable for CIP and SIP cleaning
Odourless , Tasteless, Non-Toxic Certification: FDA, USP,BFR, USDA, ISO 10993
Length: Standard maximum length is 10 meters
** PRESSURE DECREASE BY 1% FOR EVERY 1 。C ABOVE 100 。C
Platinum-cured silicone tubing PT is mainly used in pharmaceutical, biomedical, cosmetic and food applications.PT unreinforced translucent silicone tubing is not suitable for infusion, continuous steam service or high-pressure environments.
-60 °C to +200 °C
Standard: translucent. Other colors are available upon request.
FDA, USP, BFR, USDA, ISO 10993
| Code | ID (in.) | ID (mm) | Wall Thickness (in.) | Wall Thickness (mm) | OD (in.) | OD (mm) |
|---|---|---|---|---|---|---|
| PT00760167 | 0.03" | 0.76 | 0.018" | 0.46 | 0.066" | 1.67 |
| PT00760406 | 0.03" | 0.76 | 0.065" | 1.65 | 0.160" | 4.06 |
| PT01020218 | 0.04" | 1.02 | 0.023" | 0.58 | 0.086" | 2.18 |
| PT01590318 | 0.063" | 1.59 | 0.031" | 0.79 | 0.125" | 3.18 |
| PT01590476 | 0.063" | 1.59 | 0.063" | 1.59 | 0.188" | 4.76 |
| PT01980358 | 0.078" | 1.98 | 0.031" | 0.79 | 0.141" | 3.58 |
| PT02380556 | 0.094" | 2.38 | 0.063" | 1.59 | 0.219" | 5.56 |
| PT02380714 | 0.094" | 2.38 | 0.094" | 2.38 | 0.281" | 7.14 |
| PT03180635 | 0.125" | 3.18 | 0.063" | 1.59 | 0.250" | 6.35 |
| PT03180794 | 0.125" | 3.18 | 0.094" | 2.38 | 0.313" | 7.94 |
| PT03180953 | 0.125" | 3.18 | 0.125" | 3.18 | 0.375" | 9.53 |
