Application
Food, beverage, potable water, cosmetics, pharmaceutical and other high-purity industries.
Construction
Platinum-cured silicone hose, reinforced with fiberglass braid.
Temperature Range
-60 ºC to 260 ºC
Color
Standard: translucent. Other colors are available upon request.
Application
Suitable for the transfer of high-temperature fluids.Compatible with CIP and SIP cleaning.Not recommended for vacuum service.
Approvals & Certifications
FDA, USP, BFR, USDA, ISO 10993
Length
Standard length up to 50 m. For longer lengths, please contact us.
Food, beverage, potable water, cosmetics, pharmaceutical and other high-purity industries.
Platinum-cured silicone hose, reinforced with fiberglass braid.
-60 ºC to 260 ºC
Standard: translucent. Other colors are available upon request.
Suitable for the transfer of high-temperature fluids.Compatible with CIP and SIP cleaning.Not recommended for vacuum service.
FDA, USP, BFR, USDA, ISO 10993
Standard length up to 50 m. For longer lengths, please contact us.
| Code | ID (in.) | ID (mm) | OD (mm) | Bend Radius (mm) | Working Pressure (bar) | Burst Pressure (bar) |
|---|---|---|---|---|---|---|
| GF003 | 1/8" | 3 | 9.0 | 15 | 21 | 63 |
| GF004 | 1/6" | 4 | 10.0 | 20 | 20 | 60 |
| GF005 | 3/16" | 4.8 | 11.0 | 25 | 18 | 54 |
| GF006 | 1/4" | 6.4 | 13.2 | 40 | 17 | 51 |
| GF008 | 5/16" | 7.9 | 15.5 | 45 | 15 | 45 |
| GF010 | 3/8" | 9.5 | 17.0 | 60 | 14 | 42 |
| GF013 | 1/2" | 12.7 | 22.0 | 70 | 11 | 33 |
| GF016 | 5/8" | 15.9 | 25.0 | 85 | 10 | 30 |
| GF019 | 3/4" | 19 | 31.0 | 95 | 9 | 27 |
| GF022 | 7/8" | 22 | 34.5 | 145 | 6.5 | 19.5 |
| GF025 | 1" | 25.4 | 36.0 | 160 |
