3-PC Ball Valve Clamp End With Handle C3B-CLM(3A )

3-PC Ball Valve Clamp End With Handle C3B-CLM(3A )


•Blow-Out Proof Stem
•Investment Casting Body
•Standard:Butt Welding ASME BPE & 3A
•Locking Device Handle Available
•Locking Device Handle Available
•Working Temperature:-20° C~132° C
•Working Pressure:1.0Mpa
•Shell Testing:1.5Mpa
•Inspection & Testing Acc:API598


•Blow-Out Proof Stem

•Investment Casting Body

•Standard:Butt Welding ASME BPE & 3A

•Locking Device Handle Available

•Locking Device Handle Available

•Working Temperature:-20° C~132° C

•Working Pressure:1.0Mpa

•Shell Testing:1.5Mpa

•Inspection & Testing Acc:API598
