PFA‑Lined 45° Tri‑Clamp Elbow PL45ETC

The tri‑clamp conforms to 3A standards.The elbow has a 45° angle and is manufactured from food‑grade PFA granules via high‑temperature compression molding and sintering.

It features a smooth, flat surface and meets hygienic design requirements.Unique flanging technology is applied to the end ferrules,ensuring the liner is firmly bonded to the stainless steel body with no curling or delamination during long‑term service.

Operating temperature range:-60 ℃ to +230 ℃

Optional standards and materials:

1. Clamp standards: 3A, BPE, SMS, DIN, ISO, etc.

2. Body material: SS316, SS316L, etc.

3. Liner material: FEP granules or PTFE powder compression molded.

4. Anti‑static conductive PFA / FEP / PTFE available upon request.
